Pelletizer (Rotary Cutter)
■ Specification ※ If you click the model name, you can see the details.
Applications Model |
Power (Inverter Drive) |
Rotor Length |
Strand Speed |
Q’ty of Strands (Max) |
Polymer Alloying |
Master batch Compounding |
Fillers & GF Compounding |
Direct film & Sheet processing |
|
|---|---|---|---|---|---|---|---|---|---|
| Unit | Kw (AC) | mm | m/min | Q’ty | Kg/Hr | ||||
| HWEP-32R | Basic | 1.75 | 45 | 30~90 | Ø3 * 4 | 150 | 170 | 160 | 80 |
| Super | 30~90 | Ø3 * 6 | 180 | 210 | 240 | 100 | |||
| HWEP-43R | Basic | 3.75 | 120 | 30~90 | Ø3 * 7 | 220 | 260 | 300 | 130 |
| Super | 30~90 | Ø3 * 10 | 270 | 320 | 360 | 160 | |||
| HWEP-58R | Basic | 5.50 | 200 | 30~90 | Ø3 * 11 | 390 | 440 | 480 | 210 |
| Super | 30~90 | Ø3 * 21 | 470 | 530 | 580 | 260 | |||
| HWEP-75R | Basic | 7.50 | 300 | 30~90 | Ø3 * 61 | 830 | 1000 | 1100 | 500 |
| Super | 30~90 | Ø3 * 75 | 1000 | 1200 | 1350 | 600 | |||
| HWEP-102R | Basic | 11 | 600 | 30~90 | Ø3 * 95 | 1950 | 2250 | 2550 | 1100 |
| Super | 30~90 | Ø3 * 101 | 2350 | 2700 | 3100 | 1350 | |||
| Common Matters | □ Power Source : 440V * 3P * 60(50)Hz □ Control Panel : Internal Inverter, Separate Control Type (Display and Control of Speed, Ampere = Manual & Auto, Emergency) □ When main operate & local panel are interlocked, separate construction is required. |
||||||||
