Screen Changer
■ Specification ※ If you click the model name, you can see the details.
| Model | Type | Heater Capacity | Working Pressure | Hy’d Tank Capa | Include Item |
|---|---|---|---|---|---|
| HWES-32R | Hy´d Slide Dual Round Bar | Cartridge 8 Kw | 160 Kgf/㎠ | 30 ℓ (High Pre`s) | 1. Thermocouple : 3 PCS 2. Breaker Plate : 2 EA 3. Piping : Not Included 4. Hydraulic Unit ▷ Pump Motor : 1 SET ▷ Pressure Switch : 1 PC ▷ Terminal Box : 1 SET |
| HWES-43R | Cartridge 10 Kw | 180 Kgf/㎠ | 30 ℓ (High Pre`s) | ||
| HWES-58R | Cartridge 12 Kw | 220 Kgf/㎠ | 50 ℓ (High Pre's) | ||
| HWES-75R | Cartridge 15 Kw | 270 Kgf/㎠ | 50 ℓ (High Pre's) | ||
| HWES-102R | Cartridge 20 Kw | 350 Kgf/㎠ | 60 ℓ (High Pre's) | ||
| Common Matters | □ Power Source : 440V * 3P * 60(50)Hz □ Control Panel : Open, Close, Emergency Button Switch type □ When main operate & local panel are interlocked, separate construction is needed. |
||||
