Rheotruder (Single Screw)
The main device of this product is made up of Ø45 single screw shaft (L/D=10), and Ø60 (L/D=2) (L/D=4) can be used in replacing work by using sub lift (hydraulic) as a sub device and test properties in accordance with grade type.
■ Specification ※ If you click the model name, you can see the details.
| Model | Type | Test Range (Main) | Test Range (Sub) | Speed | Torque |
|---|---|---|---|---|---|
| HWSE-60 | 2-Stage Single Screw | Ø45 (L/D=10) | Ø60 (L/D=2) (L/D=4) | 80~3000 rpm | 1850 Nm |
| Common Matters | □ Power : AC15Kw*380V*3P □ Test Range : Single Screw Ø45 (L/D=10), Ø60 (L/D=2) (L/D=4) □ Analysis and characterization of properties and data input / output according to grade □ Extraction of resin pressure, temperature, and torque rate, measurement of viscosity, and analysis of melting state by speed and section about possessed model |
||||
