Side Feeder (Twin Screw)

Co-rotating Twin Screw Type Side Feeder
“HWE” Series with easy repair as well as high speed & torque.
Securing unused space in comparison with the installed site, Rotational Design to prevent a safety accident.

Side Feeder (Twin Screw)

■ Specification ※ If you click the model name, you can see the details.

Model Main Hopper (chute) About
Motor Speed Feed Type Motor Speed Mat’l Capa
HWEF-32 AC 0.75 Kw Inverter
32~360 rpm
Twin Screw L/D= 7 Standard Straight GF, CF ~40% 100 Kg/Hr
HWEF-43 AC 1.50 Kw 200Kg/Hr
HWEF-58 AC 2.20 Kw Agitator AC 0.40 Kw 30 rpm 300 Kg/Hr
HWEF-75 AC 3.70 Kw AC 0.75 Kw 400 Kg/Hr
HWEF-102 AC 5.50 Kw AC 1.50 Kw 36 rpm 650 Kg/Hr
Common Matters □ Power Source : 440V * 3P * 60(50)Hz
□ Feed Cylinder : Water Cooling Jacket
□ Including Base Sliding Rail
Control Panel : Adjusting Speed (Main = Inverter, Agitator = Fixing), Attaching Manual, Automatic Operation S/W and Emergent Button
□ This product is single control type, and O/P & Local Panel linkage is another case.
