Side Vent-stuffer (Twin Screw)
This is the equipment which emits the inevitable steam
& vacuum gas by compounding purpose as well as removes
the percentage of water content by inputting ABS Wet Powder.
■ Specification ※ If you click the model name, you can see the details.
| Model | Type | Screw (O.D) | Screw | Electric Heater | Main Motor (Power) | Main Motor (Speed) |
|---|---|---|---|---|---|---|
| HWEV-142 | Twin Screw | Ø 142 | 12~120 rpm | 10 Kw | 7.5Kw (60Hz) | 180~1800 rpm |
| HWEV-172 | Ø 172 | 11.6~116 rpm | 15 Kw | 15Kw (50Hz) | 145.4~1454 rpm | |
| Common Matters | □ Power : 440V * 3P * 60(50)Hz □ Join Adapter & Cylinder Heating= Elec’t □ Control Panel : Speed Control (Inverter), Attaching manual and automatic operation S/W and alarm button □ This product is single control type, and O/P & Local Panel linkage is another case |
|||||
