■ Specification ※ If you click the model name, you can see the details.

Model Type Elec’t Heater Capa Clamping Force Sealing Method Die Hole Q’ty (Max)
HWED-32B Handling Hinge Bolting Brass 5 Kw 3,000 kgf Breaker Plate Ø3.5 * 10 Hole
HWED-43B Brass 8 Kw 5,300 kgf Ø3.5 * 20 Hole
HWED-58B Brass 15 Kw 9,700 kgf Ø3.5 * 35 Hole
HWED-75B Brass 25 Kw 15,000 kgf Ø3.5 * 60 Hole
HWED-102B Brass 40 Kw 30,000 kgf Ø3.5 * 90 Hole
Common Matters □ Power Soruce : 440V * 3P * 60(50)Hz □ Clamping Method : Bolting
□ Electric Heater, Thermocoupling, Breaker & Die Plate are included.
□ Resin Pressure and Temperature Gauge are separated Items.
□ This product is configured in a single control type and all installation work is separate.
